200W H4 Series High Lumen LED Torch Light High Bay Canopy Lights

HANGZHOU ZGSM TECHNOLOGY CO., LTD.
  • Light Source：LED
  • Light Source Type：LED
  • Cover Material：Die-Cast Aluminum
  • Style：Modern simplism style
  • Shape：Square
  • Base Material：Die-Cast Aluminum

Base Info

  • Model NO.：ZGSM-GCD200H4
  • Voltage：100-240V ,277V
  • With Light Source：With Light Source
  • Beam Angle：110
  • Certification：CE, RoHS
  • Applicable Places：Factory
  • Folded：Folded
  • Life：100, 000h
  • Power Source：AC 100-240V ,277V
  • Color：White
  • Application：Gas Station
  • Lumen Output：28000 Lm
  • Ik Rating：Ik10
  • Heat Radiator：Anodized Aluminum
  • LED：Lumileds
  • Driver：Meanwell
  • Transport Package：1 Unit,Carton
  • Specification：200W
  • Trademark：ZGSM
  • Origin：China
  • HS Code：94054090
  • Production Capacity：3500PCS,Month

Description

SpecificationsModelZGSM-GCD200H4LED BrandLUXEON® TX/LGDriver BrandMeanwell HLG seriesNorminal Wattage200WInput Voltage100-240/277VACPower Efficiency>90%Power Factor>0.9Lamp Rated Luminous Efficiency>140lm/wLamp Rated Lumen output28000 lm (Lumen tolerance +/- 5%)Color Rendering IndexRa>70Color Temperature3000 4000 5000 or 5700KPhotometric Type110 degreesOptimal Operating Temperature25ºCStorage Temperatures-40ºC~+70ºCWorking EnvironmentBetween-40°C~+50°C, 10%~90%RHTotal Harmonic Distortion< 10%Lumen Maintenance> 100,000 hours -L70, @25 ºC (77 ºF)Body and Shell MaterialsAnodized AluminumIP RatingIP66 with test reportIK RatingIK10 with test reportCertificationCE,ROHS,GS,CBOptional Function1-10V DC or PWM Signal or Resistance DimmingTimerWarranty7 years Packing DetailsFixture Dimension585 x340 x156 mmFixture Weight7.2 kgPacking Dimension635 x365 x160 mmPacking Weight8.3 kg
Our Services
1.Reply your inquiry in 24 working hours.
2.Customized design is available,OEM and ODM are welcomed.
3.Delivery the goods to our customer all over the word with speed and precision.
4.Offer customer the lowest price with high quality product
5.We can supply C/O (Certificate of Origin), saving approx 20% import duty.
