• Model NO.：LC8201S
• Certification：CE, RoHS
• Voltage：100-240V
• Applicable Places：Restaurant,Conference Room,Hotel
• Model：LC8201s
• CCT：3000-6000K
• Power：7W,20W,30W
• Warranty：2 Years
• Size：Dia 85*H70mm
• Input：22VDC,350mA
• Lumen：400-600lm
• Surface Color：Silver,Black
• CRI：More Than 80
• Chip：Osram
• Transport Package：Natural Packing, Lesun Package or Carton Package
• Specification：CE and Rohs
• Trademark：LESUN
• Origin：China
• HS Code：94054090
• Production Capacity：1000PCS,Day

Basic Info.

Model NO. LC8201S Certification CE, RoHS Voltage 100-240V Applicable Places Restaurant/Conference Room/Hotel Model LC8201s CCT 3000-6000K Power 7W/20W/30W Warranty 2 Years Size Dia 85*H70mm Input 22VDC/350mA Lumen 400-600lm Surface Color Silver/Black CRI More Than 80 Chip Osram Transport Package Natural Packing, Lesun Package or Carton Package Specification CE and Rohs Trademark LESUN Origin China HS Code 94054090 Production Capacity 1000PCS/Day

Product Description

New 7W/20W/30W adjustable beam angel variable focus led ceiling downlight LC8201S


Model:LC8201S
Dimention: dia85*L70mm
Installation: Trackway mounting
Power:1W
Beam angel:15-60D
CCT:3000K-6000K
Lumen:400-600lm
CRI: more than 80
Surface color: white/black
Matched power supply : contant current input
100-240Vac

Descriptions:
> High brightness led ceiling light
> Adjustable type
> Recess mounted
With LED lens, which supply the 24degree angle beam light
>Various LED color are available(warm white, cool white)
> Cool operating temperature
> Order LED controller separately
> Non-dimmable
> Easy plug connector are supplied if requested
Applications:
>Office buildings, Supermarkets, Emporiums
>Hotels and restaurants, Decorating lamp
>Running lamp, Exhibition hall, Building outline
>Parks and palace decoration



Recessed led ceiling light packing & details:
Packing detail: Carton box
Delivery detail: Within 3-5 working days after receive the payment

15W recessed led ceiling light features:
1) Adopt high brightness and low light decline led;
2) Wide voltage and constant current design;
3) Well-design of thermal structure;
4) 60-80% energy saving than traditional lamps;
5) Long lifetime, over 5, 0000 hours 6) Warranty quality: 2 years
7) Instant start, no flashing;
8) Pro-environment, no UV or other radiation;
9) Low maintenance cost;
10)Low electro-magnetic radiation
11)No mercury, environment friendly.
12)Luminescence without heat radiation.
13)No UV or IR radiation, Harmless to human body

Applications:

1. Living room, bedroom, kitchen, washroom;
2. School, university, hospital, hotel;
3. Conference, meeting room, show room, showcase;
4. Commercial complexes;
5. Factory, plant, warehouse, office;
6. Supermarket, department store
7. Jewelry store, hotel and fashion shop etc

Advantage:

1. High light transmittance lens, wonderful show effect

2. Perfect design with full application of air convection principle, good heat dissipation

3. Exquisite frosted surface, long durable

4. Competive price, good looking

5. Enviroment protecting

6. Energy saving

Insturctions:

1. Lamps input is a low-voltage DC, please mention the positive terminal (the red) and the negative terminal (the black) when connecting.
2. If you want to add or reduce lamp, it must use series connection.
3. When installing make sure the power is off. Before connecting lamp and LED driver, collide the two lines to release spare power. Only after this procedure, then to electrify.
4. Don't pull the line crudely.











Good servious:

1. Good after-sales service, warranty 2 years.
2. Your inquiry related to our products or prices will be replied in 24hrs.
3. OEM&ODM, any your customized lightings we can help you to design and put into product.
4. Distributoership are offered for your unique design and some our current model
5. Protection of your sales area, ideas of design and all your private information

Model	LC8201S
Power	7W/20W/30W
Light source	cob
CCT	3000-6000K(warm white/natual white/cool white)
Beam angel	from 15° to 60degree
Size	dia85*70mmL
lumen	400-600lm
Surface color	white/black
