• Model NO.：ZGSM-GCD80H4
• Voltage：100-240V ,277V
• With Light Source：With Light Source
• Beam Angle：110
• Certification：CE, RoHS
• Applicable Places：Factory
• Folded：Folded
• Life：100, 000h
• Power Source：AC 100-240V ,277V
• Color：White
• Lumen Output：11200 Lm
• Ik Rating：Ik10
• Heat Radiator：Anodized Aluminum
• LED：Lumileds
• Driver：Meanwell
• Transport Package：1 Unit,Carton
• Specification：80w
• Trademark：ZGSM
• Origin：China
• HS Code：94054090
• Production Capacity：3500PCS,Month

SpecificationsModelZGSM-GCD80H4LED BrandLumiledsDriver BrandMeanwell HLG seriesNorminal Wattage80WInput Voltage100-240/277VACPower Efficiency>90%Power Factor>0.9Lamp Rated Luminous Efficiency>140lm/wLamp Rated Lumen output11200 lm (Lumen tolerance +/- 5%)Color Rendering IndexRa>70Color Temperature3000 4000 5000 or 5700KPhotometric Type110 degreesOptimal Operating Temperature25ºCStorage Temperatures-40ºC~+70ºCWorking EnvironmentBetween-40°C~+50°C, 10%~90%RHTotal Harmonic Distortion< 10%Lumen Maintenance> 100,000 hours -L70, @25 ºC (77 ºF)Body and Shell MaterialsAnodized AluminumIP RatingIP66 with test reportIK RatingIK10 with test reportCertificationCE,ROHS,GS,CBOptional Function1-10V DC or PWM Signal or Resistance DimmingTimerWarranty7 years Packing DetailsFixture Dimension336 x340 x156 mmFixture Weight4.4 kgPacking Dimension415 x365 x160 mmPacking Weight5.2 kg
Our Services
1.Reply your inquiry in 24 working hours.
2.Customized design is available,OEM and ODM are welcomed.
3.Delivery the goods to our customer all over the word with speed and precision.
4.Offer customer the lowest price with high quality product
5.We can supply C/O (Certificate of Origin), saving approx 20% import duty.
