• Model NO.：EBH
• Voltage：100-277V
• With Light Source：With Light Source
• Beam Angle：120
• Certification：CE, RoHS, UL, ISO9001, CCC, SAA, CUL
• Applicable Places：Undergroud Parking, Warehouse, House etc
• Folded：Unfolded
• Ra：>80
• Power：7W
• IP：66
• Lf(mm)：178
• Transport Package：in The Box,Cotton
• Specification：GS SAA CCC UL EMC ROHS CE CUL etc
• Trademark：Yuan Hui
• Origin：Cixi, Zhejiang, China
• HS Code：9405409000
• Production Capacity：10000PCS,Month

  IP66     290x200x95       w178    410*420*315EBH-7W-H     7W    550      48     290x200x95       L268    410*420*315                             2.Technical Features:
  1.Input Voltage: 100-277V
  2.Frequency: 50/60Hz
  3.IP Rate: IP66
  4.Driver : constant current  LED driver
  5.Lumen:550lm
  6.LED Source: SMD2835
  7.LED Chip: Lextar, Epistar, SAMSUNG
  8.CCT: 3000K 4000K 5000K 6500K
  9.Ra: >80
 10.Luminous Efficiency: >85lm / W
 11.Working Temperature: -20 ºC to +40 ºC
 12.Warranty: 5 Years
3.Description:
  1.Polycarbonate injection mould housing, with silicon gasket to guarantee IP65 protection.
  2.Opal polycarbonate diffuser with UV protection, high impact resistant IK10.
  3.Rapid connection system.
  4.Easy installation with 304 stainless fixation to the ceiling.
4.Product Options:
  1.Emergency pack
  2.Microwave senser
  3.Dimmable driver
 IP66Opal1100RBH-14W-W14W96PCS1100RBH-7W-H7W48PCS520 3000K,4000K,6500K288x288x88φ2688595x35x315φ301x95φ2818625x410x325φ301x95φ2818625x410x325
Production description
Input Voltage : AV220-240V or AV100-277V,60/60Hz
IP rATING : IP66,Class : I I
Driver : CONSTANT current LED  driver .
Housing ; Polycartbonate material , high impact resistant , IK10 .
GWT 850 degrees ,white or black color for your option .
Diffuser : Polycarbonate material , high impacy resistsnt ,IK10.
GWT 850 degrees ,UV protetion.
High temperature resistant PCB for SMD LED
Natural silicon gel gasket ,ensure waterproof dustproof
With cable gland for the good waterproof function .
Quick wiring system ,save installation time ,save money
Easy and quick installation under celling or wall-mounted
Warranty : 3 years
It could be fitted with sensor and emergency function
Suitble for corridor ,undergound parking ,warehouse,etc


FAQ:

Q1: Can I have a sample order for led light?
A1: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.

Q2: What is the lead time?
A2: Samples need 3-5 working days, mass products need 7-10 days.


Q3: Do you have any MOQ limit for led light order?
A3: Low MOQ, 1pc for sample checking is available.

Q4: How do you ship the goods and how long does it take to arrive?
A4: We usually ship by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive. Airline and sea shipping also optional.

Q5: How to proceed an order for led light?
A5: Firstly let us know your requirements or application.Secondly We quote according to your requirements or our
suggestions.Thirdly customer confirms the samples and places deposit for formal order. Fourthly We arrange the production.

Q6: Is it OK to print my logo on led light product?
A6: Yes. Please inform us formally before our production and confirm the design firstly based on our sample.

Q7: Do you offer guarantee for the products?
A7: Yes, we offer 2-5 years warranty to our products.

Q8: How to deal with the faulty?
A8: Firstly, Our products are produced in strict quality control system and the defective rate will be less than 0.2%.
Secondly, during the guarantee period, we will send new lights with new order for small quantity.
For defective batch products, we will repair them and resend them to you or we can discuss the solution including re-call according to real situation.
