LED Indoor Luminaires Modern Verticale Pico Fixtures Simple Parete Singolo Letto Pendant Aura Wall Decorative Bedroom Light

Zhongshan Camilamp Lighting Co., Limited
  • Material：Steel
  • Style：Modern
  • Light Source：LED
  • Shape：Arc
  • Certification：CE, RoHS, UL, CCC, VDE, ETL,PSE,SAA
  • Voltage：Euro 90-264V,Us 277V

Base Info

  • Model NO.：EC-1046-T
  • Switch Type：Touch Switch
  • Lamp Holder：LED Strip
  • Quantity of Lights：LED Strip
  • With Light Source：With Light Source
  • Material & Description：Stainless Steel + Silica Gel
  • Process：Electroplating
  • Transport Package：47*17*19.5
  • Specification：L400*W120*H90
  • Trademark：Camilamp,Customized
  • Origin：Guangdong, China
  • HS Code：9405990000
  • Production Capacity：5000

Description

 Product Specification  Watch VideosCooperated Provision  QuotationInstallation Instruction&Tip  ComplaintAgent certification Product Namearc Table  LED  light Product CodeEC-1046-T MOQ (PCS)100 Payment TermPayment terms-TT, 30% deposit, 70% balance must be paid before delivery. Irrevocable  L/C at sight. West union, paypal Delivery Time15-20 Days after deposit
★  Product Overview and applicationLED Indoor Luminaires Modern Verticale Pico Fixtures Simple Parete Singolo Letto Pendant Aura Wall Decorative Bedroom LightLED Indoor Luminaires Modern Verticale Pico Fixtures Simple Parete Singolo Letto Pendant Aura Wall Decorative Bedroom LightAreas of application

_ Indoor Kitchen/Meeting Room/Relaxing
_ Bar/Counter/hotel/Hallway
_ Bedroom/Living room
_ Lobby/Stair

Product family benefits

_ Bright and efficient LED light source that provides superior light quality with wall light CRI >90
_ Low cost operation: - Saves 80% energy compared to other Eliminates the cost of over 6MULTI replacements over the life of the fixture (L70 = 30000 hrs)
_ Stainless steel with perfect Finishing
_ Environmental friendly: No hazardous materials
_ UGR ≤ 20
_ SDCM ≤ 5
_ PF ≥ 0.9
_ Flickering ≤ 5%

Product family Features

_ Long lifetime: up to 30,000 h
_  Stainless steel  + Optical Silica Gel
_ Light Efficiency: up to 100 lm/W
_ Combination of easy and flexible use

Technical data
General Product information
Product NumberEC-1046-T
Product NameARC LED  WALL light
Brand NameCAMILAMP Lighting
Dim MethodNormal, OR OPTIONAL (DALI, ZIGBEE, BLUETOOTH TUYA, TRIAC PHASE CUT; 0-10V);
THD at Ta≤ 20 (EN61000-3-2)
General Description
 		WALL LED, IP20,
Watts optional (Each Ring) : 12W (Max)
L-N 1KV, L/N-PE 2KV (IEC60598)
IEC 60598Fulfill
Average Rated Life30000 h at normal T
Operating Temperature Range
(90% Lumen output - ambient temperature)		-10°C to 40°C
Operating Temperature Range
(normal and any variations required)		-20°C to 70°C
Quality Guarantee3 Years/5years

Electrical data
Nominal Wattage12W (Max)
Nominal Voltage (Remark US or EU)198-264VAC (EU Standard)/100-277 (US Standard)
Line frequency50/60HZ
IP and IK ingressIP20/IK02
AC input current0.06A @230Vac
PF factor ≥0.9
IEC 61347Fulfill
Driver BrandOSRAM/3AAA/Eaglerise

Light Technical data
Luminous Flux1200 lumens MAX
Light General3000K/4000K
Light BrandOSRAM/BridgeLux/CREE/Sanan
CCT3000K/4000K
SCDM≤ 5
UGR≤ 22
Light Flicking ≤ 5%

Key Materials
Housing Material and Installation BoxSuperior Iron
Body Color and Installation Box colorGolden rose/Phantom
Optical Cover Silicon Gel
Cover ColorTransparent 90% rate

Additional product data
Packaging Information
Product number PackagingQuantityOutside dimensions l x w x hGross weight
EC-1046-T Shipping box (Case)100 See spec
LED Indoor Luminaires Modern Verticale Pico Fixtures Simple Parete Singolo Letto Pendant Aura Wall Decorative Bedroom Light
