• Model NO.：ZGSM-GCD150H5
• Voltage：100-240V ,277V
• With Light Source：With Light Source
• Beam Angle：110
• Certification：CE, RoHS
• Applicable Places：Factory
• Folded：Folded
• Life：100, 000h
• Power Source：AC 100-240V ,277V
• Color：White
• Application：Gas Station
• Lumen Output：19500 Lm
• Ik Rating：Ik10
• Heat Radiator：Anodized Aluminum
• LED：Lumileds
• Driver：Meanwell
• Transport Package：1 Unit,Carton
• Specification：150W
• Trademark：ZGSM
• Origin：China
• HS Code：94054090
• Production Capacity：3500PCS,Month

SpecificationsModelZGSM-GCD150H5LED BrandLUXEON® TX/LGDriver BrandMeanwell HLG seriesNorminal Wattage150WInput Voltage100-240/277VACPower Efficiency>90%Power Factor>0.9Lamp Rated Luminous Efficiency>140lm/wLamp Rated Lumen output19500 lm (Lumen tolerance +/- 5%)Color Rendering IndexRa>70Color Temperature3000 4000 5000 or 5700KPhotometric Type110 degreesOptimal Operating Temperature25ºCStorage Temperatures-40ºC~+70ºCWorking EnvironmentBetween-40°C~+50°C, 10%~90%RHTotal Harmonic Distortion< 10%Lumen Maintenance> 100,000 hours -L70, @25 ºC (77 ºF)Body and Shell MaterialsAnodized AluminumIP RatingIP66 with test reportIK RatingIK10 with test reportCertificationCE,ROHS,GS,CBOptional Function1-10V DC or PWM Signal or Resistance DimmingTimerWarranty7 years Packing DetailsFixture Dimension439 x340 x156 mmFixture Weight5.4 kgPacking Dimension485 x365 x160 mmPacking Weight6.3 kg
